2 Notes to the Text

2  Notes to the Text

1.

A New England journal associated with transcendentalism, a philosophical viewpoint shared by Emerson, Thoreau, and others, which has been described as ‘‘a cosmic idealism coupled with Yankee practicality, Puritan pugnacity, and grasp of fact.’’ Thoreau’s Walden is an experiment in spiritual and physical autonomy which, though anti-urban and anti-industrialization, hints at Fuller’s taking growthful and propagative advantage of nature’s universal patternings.

2.

Main quotations in this chapter, ‘‘The Formative Years,’’ are extracted from a long biographical letter written by Fuller to the author in 1955. Complete text published in Architectural Design (London), July, 1961.

3.

James Monroe Hewlett (1869-1941): President, Architectural League, New York 1920--21; President, Society of Mural Painters 1922; Vice-President and Fellow American Institute of Architects 1928; Director, American Academy in Rome 1932--35. Murals include ceiling of Grand Central Terminal, New York City, many stage designs in New York for Metropolitan Opera, etc.

4.

The peak year of U.S. building was 1925. Of 572,000 singlefamily dwellings produced then, only 270 had any interior plumbing. Less than 4 per cent were erected with union labor, less than 2 per cent architect designed. The current shortage was estimated at around 6,000,000 minimal standard dwellings.

5.

4D essays were incorporated in R. B. Fuller, ‘‘4D Timelock’’ (see Bibliography). Fuller’s use of 4D as a symbol makes reference to ‘‘time’’ in relativity theory, as a (4th) extension of physical dimension. But latent connotations go further; during this period Fuller seemed preoccupied with time accounting, and conducted a number of experiments in rearranging his work/sleep schedules, etc.

6.

Fuller also drew up, at this time, his ‘‘Universal Requirements of a Scientific Dwelling Facility’’ check list. Begun as a control schedule for the Dymaxion House, this has been considerably amplified over the years. Exhaustively detailed, in accordance with his maxim that ‘‘in the adequate statement of a problem lies its solution,’’ this document attempts to list every requirement, and meet most contingencies, likely to occur to man in relation to shelter. Also dealt with are the step-by-step design and prototype procedures and the industrial logistics which he saw as required for its implementation. For the latest version, published in 1960, see Bibliography.

7.

P. R. Banham, Theory and Design in the First Machine Age, London, 1960, pp. 323--26, says, referring to the Dymaxion House, ‘‘…had it been built, [it] would have rendered Les Heures Claires [Le Corbusier’s design of 1930], for instance, technically obsolete before design had even begun.’’

244--8. Arthur Drexler, in his book, Ludwig Mies van, der Rohe (New York: George Braziller, Inc., 1960), gives a clue to this when he says that ‘‘Mies builds as if technology means only post and lintel construction,’’ pp. 9--10.

9.

Though aircraft production rose to 2,000 planes in 1927, and the first passenger airline service in the United States opened between New York and Boston, the lightweight alloy aircraft construction implied in the house was not in general mass production in the United States. Junkers had used metal-stressed skin surfaces, with box-spar construction since 1919; and the 1920 Short ‘‘Silver Streak’’ had duralumin fuselage and wings, but the major production innovation of 1927 was the Lockheed ‘‘Vega’’---wooden wings, and stressed skin wood fuselage, but of advanced streamline shaping.

10.

Quotations of Fuller in this chapter are taken from various letters written during World War II.

11.

For expansion of Energy formulation, see World Energy Map (plate 31).

12.

The four illustrations in plate 35 are given as reproduced by John J. Grebe, Director of Nuclear and Basic Research, Dow Chemical Company, in his paper on ‘‘A Periodic Table for Fundamental Particles,’’ delivered before the New York Academy of Sciences, in which he cites Fuller’s work: ‘‘These models could represent the structure of the so-called elemental particles mathematically, although not necessarily physically---too little is known to say that. However, it does seem as if these successive layers are significant in the properties---particularly the slow neutron cross-sections---of isotopes, from the smallest nuclear masses to those of the 26th shell, and including both lead and bismuth…’’

13.

In the 19th century, van’t Hoff suggested that all inorganic chemical structures were tetrahedronally configured invertexial linkage. Linus Pauling’s X-ray diffraction analyses of 1932 showed omni- tetrahedronal configuration interlinkages of gravitational centers of compounded atoms in all metals analyzed. Lord Kelvin, and later, A. Graham Bell, empirically used tetra units as building blocks in structural systems. For diagrams of tetra valency bond, see: G. S. Christiansen and P. H. Garrett, Structure and Change (San Francisco : W. H. Freeman & Co., 1960).

14.

The term ‘‘geodesics’’ was first used by Hertz, the discoverer of electro-magnetic waves. It was used mathematically by Einstein and Ryman. Fuller defines geodesics as the most economical relationship between a plurality of points or events. Minkowski suggested that the laws of nature may find their most perfect expression in statements about intrinsic topological relations between world lines (geodesics) in some fairly general continuum.

15.

Prior to Fuller, geodesic structure was mainly applied only in approximately single curvature structures---as conic (masts), hyperbolic (cage masts), cylindrical and elliptical (airframes) spiraling 45 and in lamella roofs. Fuller’s geodesics are inherently compound curvatures, i.e., finite systems. It was unknown mathematically, before energetic/synergetic geometry that any modular frequency of a symmetrical subdivision of spherical or linear tetrahedrons, octahedrons or icosahedrons provides spring points for geodesic 3-way grid interactions.

16.

A. N. Whitehead, as quoted by Fuller in ‘‘The Comprehensive Man,’’ Northwest Review, Spring, 1959.

17.

A striking aspect of Fuller’s system is that many of its procedures may be conceptually modeled through the employment of his Energetic Synergetic Geometry. In the trend toward modelability evident in current scientific development (e.g., in systems simulation, modelable analogies of whole systems, etc.), this geometry has received a number of citations of congruence with observed behaviors in many fields. Confirmation of its alignment with structural discoveries, particularly evident since the increased use of electron microscopy, has occurred in the study of virus and protein molecules as well as fundamental particles. (See, for instance, ‘‘Drug Against a Virus,’’ Time magazine, February 16, 1962, p. 50, and ‘‘Virus, a Triumph and a Photograph,’’ New York Herald Tribune, February 6, 1962, pp. 1 ff., as well as note 12, supra.} Certain of the diagrams and conceptual hypotheses employed in mathematical analysis in the social sciences (e.g., ‘‘radex,’’ ‘‘circumplex’’ figures, and others) show parallel similarities as yet not fully realized. (For discussion of radex and circumplex, see: P. F. Lazarsfeld, ed., Mathematical Thinking in Social Sciences (Glencoe, Illinois: Free Press, 1954.) This rational ‘‘all energy behavior accounting’’ mathematical tool has recently been further developed by Fuller in a series of papers called ‘‘Omni-directional Halo.’’ These new insights extend and amplify the postulates of the geometry into the area of a more generalized epistemology, in a manner which provides a formidable intellectual apparatus for the elucidation and reduction of complex phenomenon relationships.

3 Biographical Chronology

4 1895 Born July 12, in Milton, Massachusetts

5 1904--13 Student at Milton Academy

6 1913--15 Harvard University

7 1914 Apprentice machine fitter, Richards, Atkinson and Has- erick

8 1915--17 Various positions, Armour and Company, New York City

9 1917 United States Navy

10 July 12th, married Anne Hewlett

11 1919 Discharged as lieutenant, United States Navy, at end of World War I

12 1919--21 Assistant Export Manager, Armour and Company, New York City

13 1922 Sales Manager, Kelly-Springfield Truck Company

14 1922--27 President, Stockade Building System

15 1927--32 Founder and President, 4-D Company, Chicago

16 1930 Assistant Director of Research, Pierce Foundation

17 1932--35 Founder, Director, Chief Engineer, Dymaxion Corporation, Bridgeport, Connecticut

18 1936--38 Assistant to Director, Research and Development, Phelps Dodge Corporation

19 1938--40 Technical Consultant, Fortune magazine

1941.

42 Vice-president, Chief Engineer, Dymaxion Company, Inc.,

20 Delaware

1942.

44 Chief Mechanical Engineer, Board of Economic Welfare.

21 Special Assistant to Director, Foreign Economic Administration

22 1944--46 Chairman of the Board and Administrative Engineer, Dymaxion Dwelling Machines

23 1952 Award of Merit, New York Chapter of the American Institute of Architects

1954.

Award of Merit, United States Marine Corps

1954.

57 Gran Premio, Triennale di Milano, Italy

1955.

Centennial Award, Michigan State University

1955.

59 President, Synergetics, Inc., Raleigh, North Carolina

24 1958 Gold Medal Scarab, National Architectural Society

25 1960 Gold Medal, Philadelphia Chapter of the American Institute of Architects

26 1960 Frank P. Brown Medal, Franklin Institute

27 1962 Charles Eliot Norton Professor of Poetry, Harvard University, Cambridge, Massachusetts

28 Currently:

29 47

30 Chairman of the Board of Trustees of Fuller Research Foundation

31 President, Geodesics, Inc., Raleigh, North Carolina

32 President, Plydomes, Inc., Des Moines, Iowa

33 Research Professor of Generalized Design Science Exploration, Department of Design, Southern Illinois University

34 Visiting Professorships have been held by Fuller at over 110 American universities and colleges

35 Life Memberships:

36 Benjamin Franklin Fellow, Royal Society of Arts, England, 1960 Fellow of the American Association for the Advancement of Science

37 Honorary Member of the American Institute of Architects

38

1.

World, Town Plan, 1927. Fuller's caplion reads: ‘‘26 per cent of earth’s surface is dry land. 85 per cent of all earth’s dry land is here shown. 86 per cent of all dry land shown is above the equator. The whole of the human family could stand on Bermuda. All crowded into England they would have 750 square feet each. ’United we stand, divided ive fall’ is correct mentally and spiritually, but fallacious physically or materially. 2,000,000,000 netv homes will be required in next 80 years.’’

39

40

2.

Ten Deck Building, 1927. Airborne by dirigible. Sketch: 1. 700-foot Zep (dirigible'), 190- foot 4-D house, anchor out, the bomb is dropped. 2. View of the shell crater and anchored Zep from above; house being maneuvered into position. 3. Down comes the 4-D tower house from the sky, featherweight ‘‘lightful construction.’’ 4. Into the hole like planting a tree. 5. Men make fast temporary stays while cement is poured above base, like setting of big guns in wartime. 6. Off goes the Zep to make a few more deliveries.

3.

Ten Deck Building. Heat losses of buildings being proportional to air drag, Fuller’s diagrams show air current effects of (A) cube, (B) cylinder, (C) streamlined unit, and underlined, by relative size and areas of turbulence, the proportional resistance of these units. This demonstrates efficiency of ivindshield in reducing drag---heat loss.

41 4. Variation of the Ten Deck Building. Construction details

42 (left) and general appearance (right).

43 5. Ten Deck Building. Model, with aerodynamic shield.

44

45

46 6. Dymaxion House. Model, 1927.

47 7. Dymaxion House. Model. House parts in shipping order.

48

49

50 Rh showing AUPPORT- 5T HT1R- IDR COMPREoilON STRUTS A HOUSE JVPPORTEDIN TW JION - HAST CONTAINS POWER Unit and serves A5 DIS - TRIBUTIN G TUBE FOR AIR LIGHT. HEAT. ETC. EXTERIOR SHELL OF ATRUTURE COMPOSED OfTRiWGUL- AR NtN SHATTER - ABLE VACUUM MD

51 TOP so tT PY- By DURMW HOOD WND OVER TOP 3 PROTECTING PERJONS - MASTHEAD CONTAINING LEN- JtS FOR UTILIZING LIGHT AND HEAT Of SUN * AREA. UNDER H0U5E III ED FOR HANGAR 6 GARAGE CLO5E IN BY METALIC VENETIAN BLINDS WORM-GEAR - ELEVATOR INIWT

52 I5D-

53 m

54 ITl- nm rn fj-

55 rr Ttft T> T.1L .5?A£E nil PLAW crrsc tc rmiM

56 LITY 111-

57 |Wy km utility units

58 ARI MANUIACT W T0T1 ATTA

59 NOT FAM - iV£?.T ■jxit or jr«H n- SIGN B IWlFuraiHJT Rfl iL£0 TO 1,-x MASTS thir it ji.'t w:r.-: £/-•? At T-PLiui BV A DESIRABLE UNIT .'S IT D=V- LLCPS. ALL Ti.nur flASilVK IS BJl'-T HTJ IITILITICS

60 AsONN Tilt MAST PIPING AND AIL CONDUIT HOOK-UP BUM. In -STANom MAMIfCD HANNER WITH COtlpnT IN MAST - AS IN CO» lIhc. ut AaIlrqao cm

61 DA5t FOR*

62 HAST CONTAINING' SEPTIC AND FUEL. TAMS

63 PLAN- I5OMLTRIC -MD -ELEVATIOM OF A MINIMUM DYMAXION HOME.

64 8. Dymaxion House. Schematic drawing and inventory of functions.

65 9. Dymaxion bathroom. Patent drawing for 1937 version.

66

67

68 11. Dymaxion bathroom unit. 1937 version. Interior.

69

70

71 13. Twin Dymaxion Deployment unit, 1940.

72

73 17. Dymaxion Deployment unit. Interior view of assembly.

74 15. Dymaxion Deployment unit. Interior, view of kitchen, bath, and bedroom unit.

75

76

77 16. Dymaxion Deployment unit. Exterior assembly.

78

18.

Autonomous Living Package. Model, 1949, with space registry of six face loads (one face open).

19.

Autonomous Living Package.
Model (partially open).

20.

Autonomous Living Package. Model (fully open).

79

80

81 21. Land and Air maneuvering Dymaxion jet-stilt, 4-D transport, 1927. Inverted

82 V bottom provides air-keel speed as well as tail-lift (for speeds over 50 mph).

83

84 22. Dymaxion car. Patent drawing filed 1933.

85

86 23. Dymaxion car No. 3,1934.

87

88

89 24. Dymaxion car No. 4,1948.

90

91 25. Wichita House, 1946. Finished, shell state with empty packing cylinder at left.

92 26. Wichita House. Model. Interior.

93

94 27. Wichita House. Atmospheric field flow studies.

95 28. Wichita House. Living room interior.

96 29. Wichita House. Parts stacked for shipping.

97

98

99 «9

100 THE TWENTIETH CENTURY

101 l»10

102 1920

103 1140

104 1930

105 1950

106 1940

107 1970

108 ION

109 1900

110 90X-

111 MX -

112 o 70X

113 MX-

114 sox

115 40X--

116 20%

117 19S2 &>«■? $!•»• Qmm*

118 10%

119 IS

120 AslaMc

121 WORLD •ARI

122 WORLD WAR 11

123 UNTIL CRITICAL POINT IS REACHES MAJORITY OF DORLO MEN ARE ‘‘HAVE HOTS’’ AN© AGS INCITABLE TO SOCIALISM BY REVOLUTION AGAINST THE SEEMINGLY EVER MORE

124 UNDULY PRIVILEGED MINORITY AFTER 1972 MAJORITY ARE ‘‘HAVES’’

125 CRITICAL POINT

126 £33 CM 1972

127 1900 100X

128 30. World Industrialization chart, 1952.

129 OX

130 INDUSTRIALLY OBJECTIVE ADVANTAGE TO INDIVIDUALS. 1.*. WHEN 100 INANIMATE ENERGY SLAVES* ARE IN CONTINUAL ACTIVE SERVICE PER EACH AND EVERY FAMILY EXISTING IN GOVERNING ECONOMY AND THOSE ENERGY SLAVES ARE PRIMARILY FOCUSED UPON REGENERATIVELY ADVANCING STANDARDS OF LIVING AND IN ARTICULATING AMPLIFYING DEGREES OF INTELLECTUAL AND PHYSICAL FREEDOMS

131 31. World Energy Map, 1940. Dymaxion projection of spherical world as a flat surface with no visible distortion. All openings in the stretched-out earth ‘‘skin’’ occur in the one and continuous ocean. This allows the particular arrangement of linked-together continental masses without breaks in their contours, surrounded by ‘‘their’’ oceans. Fourteen segments can be assembled in various combinations as three-dimensional approximation of a globe. The curved arrangements of population symbols indicate major population concentrations. Each related dot equals 1 per cent of the world's inanimate potver, called ‘‘energy slaves.’’ Energy slaves are determined as follows: In an 8-hour day, one man can do approximately 150,000 foot-pounds of work (the energy required to lift one pound one foot vertically). Consumption of mineral and water energy in 1950 is estimated at 80Vo quintillion foot-pounds. Man's efficiency converts only a rough 4 per cent of these into work, or about 3¥s quintillion foot-pounds. Dividing this by 250 work days' (one year) energy output of one man (37¥> million foot-pounds), the result is 85V2 billion man-year equivalents of work done by machines and structures. These equivalents are called ‘‘energy slaves.’’

132 There are about 38 energy slaves per capita, but:

177

178 32. Dymaxion Air Ocean JTorld Map, 1954.

179

180 33. Minni-Earth Sphere, Cornell University, 1952. Early development of Geoscope project.

181

182

183 34. Energetic and Synergetic Geometry. Models of closest packing of spheres.

184

185 35. Energetic and Synergetic Geometry. Drawing of closest packing of spheres. (A) Two-dimensional closest packing of spheres around a nucleus forms regular hexagonal patterns. Spheres can be considered as expanded vertexes of the equilateral triangles. (B) Omnidirectional closest packing. Twelve balls in first layer surrounding nucleus. (C) Omnidirectional closest packing. Forty-two balls in second layer surrounding nucleus. (D) Omnidirectional closest packing. Ninety-two balls in third surrounding layer. Thus, one ball: nucleus; 12 balls: 1st layer (radius 1); 42 balls: 2nd layer (radius 2); 92 balls: 3rd layer (radius 3); and so forth. Subtract common 2 from each total, then divide by 10; the remaining numbers (1, 4, 9, etc.) are the squares of radii. The number of balls in any layer equals (radius’ X 10)-\-2.

186

187 36. Energetic and Synergetic Geometry: (A) The tetrahedron, is minimum and therefore basic structural system; all structure is a complex of tetrahedroxel transformations. (B) Tetrahedrons are seemingly unique because they may be turned inside out and pass through zero phases of other transformations. (C) A triangle (truss) is a tetrahedron of zero phase altitude. A line is a tetrahedron of zero phase base. A point is a tetrahedron of combined zero phase of both altitude and base. (D) In addition to its four facets a tetrahedron has four vertexes and six edges. Its edges may be ‘‘straight" or ‘‘visible" arcs. (E) The regular six-chord-edged tetrahedron encloses (defines) the minimum volume ivith the most surface of all geometric polyhedrons or structural systems; whereas sphere encloses most volume with least surface and the minimum sphere-defining structure is the regular six-great-circle-arc- edged tetrahedron of 109°28' central angles and 120° surface angles. As there may be no absolute division of energetic universe into isolated or non-communicable parts, there is no absolute enclosed surface or absolutely enclosed volume; therefore, no true or absolutely defined simultaneous surface sphere integrity. Therefore, a sphere is a polyhedron of invisible plurality of trussed facets (‘‘trussed!’ because all polygons are reducible to triangles or trusses and are further irreducible) and trusses are therefore basic polygons. Infinite polyhedron is infinitely faceted by basic trusses.

188 37. Energetic and Synergetic Geometry. Geometrical development of geodesics. (A) Sphere. (B) Tetrahedron. (C) Octahedron. (D) Icosahedron.

189 . (E) Icosahedron exploded onto sphere. (F) Geodesic grid.

190 C D E F

191

192

193

194 35

195 38: Energetic and Synergetic Geometry. Early chart of 1944. This infinitely extending vector system in dynamic equilibrium provides a frame of reference in universal dimension for measurement of any energy conversion or any degree of developed energy factor disequilibrium or its predictable reaction developments.

1.

tetrahedron. Convergently or compressively organized plurality of spherical nuclei. Exterior ballistics, 2 visible, 2 invisible orbits.

2.

Divergently organized single sphere---interior compression ---exterior tension, subdivided by great circles; absolute of 2nd orbit --- maximum volume with minimum surface. Correct first subdivision of spherical surface one dimension into four. Weds % of unity of vertexes to % of unity of surface with 6 arc segments and 4 vertexes.

3.

exterior. Position in super tetrahedron convergent phase of vectors. All vertexes are spherical centers. All angles are 60°. Tetrahedron has octahedron center.

4.

Tensed interior geometric vector construction in equilibrium. Minimum volume with maximum surface. 4 equal planes perpendicular to separate axis=4 dimensions.

5.

Absolute convergence first orbit. No volume, exterior compression. Internal tension. 60° x 35° x 110° pyramids. 4 parts.

6.

Divergent components of octave subdivision. 4 small tetra, 1 small octa.

7.

Convergent and divergent unit and fractional values in high-low octaves. % or .5.

8.

octahedron. Tensive core.

9.

Interlocked vectors of 8 tetrahedrons. 3 axes.

10.

Center of octahedron is dymaxion.

11.

Eight equiangular equilateral surface triangles.

12.

Right components are 60° triangle base, 45° x 90° pyramids.
